CFIL 4-S









Order code
CFIL 4-S
Ports
G1/2"
Temperature range
max +40°C
Weight
0.6 kg
Working pressure range
0 ... 10 bar
0 ... 1 MPa
Recommended flow rate
(p = 6 bar at 25 m/s)
600 Nl/min
Pressure drop with new filter element
0.1 bar
Pressure drop with saturated filter element
0.3 bar



AUTOCAD ver 14. DWG

JPG

ACIS - SAT

STEP




Materials
