logo Pedal with 5/2 microvalve, push-in fittings for ø4 tube - valve in rear position


foto chiusa foto aperta


disegno





Cover colour: YELLOW





Code
Part number
Description
Symbol
08.323.4N
PED 504 MA
Mono-stable pedal valve 5/2, push-in fittings ø4, with protection cover
symbol
08.324.4N
PED 504 BA
Bi-stable pedal valve 5/2, push-in fittings ø4, with protection cover
symbol
08.325.4N
PED 504 SA
Mono-stable pedal valve 5/2, push-in fittings ø4, with protection cover and safety feature*
symbol
08.326.4N
PED 504 BSA
Bi-stable pedal valve 5/2, push-in fittings ø4, with protection cover and safety feature*
symbol

* Safety feature: to avoid accidental operation the pedal must be fully depressed.

The rear position of the valve allows to use a connection multitube, hiding the single air connection tubes with a better aesthetic effect.
